Epoxy
Compound | |
|
ELECTRONIC & ELECTRICAL INDUSTRIES
|
|
|
| PRODUCT CODE |
MIXING RATIO |
COLOR |
VISCOSITY (CPS, 25C) |
FEATURES AND APPLICATIONS |
|
HIGH MODULUS (Hard
type) |
| E-128 / H-128 |
3 : 1 |
Black |
5,000
/60 |
Excellent weather resistance,
hi-tensile strength.
For electronic insulation,
potting and casting. |
| E-190B / H-190 |
100 :
33 |
Black |
4,400 /
100 |
Outstanding electrical properties and
hi-thermal conduction.
Ideal for large size
electronic (LED) casting. |
| E-226R / H-120 |
100 :
40-50 |
Red |
Paste /
1,200 |
Easy to handle, non-sag epoxy
resin.
For large size electronic components adhesion
and dipping. |
| E-890A / H-105 |
2 : 1 |
Light Yellow
(white) |
2,400 /
1,500 |
Excellent weather resistance and with
glossy finishes.
For electronic (LED) casting
and coating. |
| E-1001 |
Single
Component |
White |
Paste |
General purpose
adhesives. |
| E-1022A / H-1022B |
2 : 1 |
Black |
25,000 /
350 |
Excellent weather resistance with
hi-thermal conductivity.
For insulation sealing of
electronic devices. |
| E-1025A / H-1025B |
3 : 1 |
Black |
35,000 /
350 |
Excellent weather resistance and long
pot-life.
For electronic component potting and
casting. |
| E-5260 / H-5260 |
100 :
80 |
Black |
600 /
100 |
Hi-tensile strength, low
viscosity.
For insulation, LED casting and
potting. |
| E-5600 / H-5600 |
2 : 1 |
Black |
3,000 /
600 |
Easy to handle.
For insulation,
casting and hi-thermal conductivity. |
| E-120B / H-100 |
3 : 1 |
Customize
colors |
2,100 /
30 |
Low viscosity and easy to
handle.
For general purpose of concealing
circuitry. |
| E-162B / H-162 |
3 : 1 |
Customize
colors |
|
Long pot-life.
For larger
LED casting. |
| E-769 / H-769 |
4 : 1 |
Black |
Paste /
1,200 |
Hi-viscosity, good
moisture-proof.
For capacitor insulation and potting,
and as insulating membrane. |
| E-639 / H-639 |
100 :
30 |
Customize
colors |
|
Medium viscosity, hi-voltage
resistance with hi-thermal conductivity.
For larger
electronic component LED casting. |
| E-638 / H-638 |
100 :
28 |
Customize
colors |
Paste /
100 |
High viscosity, hi-voltage resistance
with hi-thermal conductivity.
For vehicle hi-voltage
ignitor coil potting. |
| E-566 / H-5600 |
3 : 1 |
Customize
colors |
|
Medium viscosity, hi-voltage
resistance with hi-thermal conductivity.
For motor
vehicle CDI
potting. | |
|
|
| PRODUCT CODE |
MIXING RATIO |
COLOR |
VISCOSITY (CPS, 25C) |
FEATURES AND APPLICATIONS |
|
LOW MODULUS (Soft
type) |
| E-185B / H-185B |
3 : 1 |
Black |
1,050 /
40 |
Easy to handle, low viscosity and
flexible.
For electronic insulation. |
| E-721 / H-721 |
1 : 1 |
Black |
900 /
200 |
Hi-tensile strength, flexible, low
viscosity, low curing stress.
Best for precise
electronic components potting and casting. |
| E-768 / H-768 |
100 :
60 |
Black or
Blue |
2,800 /
100 |
Excellent cold resistance, good
elasticity, cured in room temperature.
For electronic
components casting and potting. |
| E-731 / H-7311 |
100 :
30 |
Black or
Clear |
4,000 /
100 |
Easy to handle, offer good import and
cold resistance.
For electronic component potting and
casting. |
| EU-960 / HU-960 |
100 :
35 |
Black |
30,000 /
550 |
Exhibit cold resistance, good
elasticity.
For electronic component potting and
casting. |
| E-X2 / H-X2 |
4 : 2 |
Customize
Colors |
6,000 /
120 |
Super-soft epoxy.
For excellent
impact and cold
resistance. | |
|
|
|
FOR
DIODES (LED industries) |
|
|
| PRODUCT CODE |
MIXING RATIO |
COLOR |
VISCOSITY (CPS, 25C) |
FEATURES AND APPLICATIONS |
| E-600 / H-600 |
1 : 1 |
Clear |
10,000 /
110 |
Optimum transparency and heat
resistance.
Ideal for luminous diodes and small size
LED casting. |
| E-605 / H-605 |
1 : 1 |
Clear |
10,000 /
100 |
Optimum transparency and heat
resistance.
Ideal for luminous diodes and large size
LED casting. |
| E-606 / H-606 |
1 : 1 |
Clear |
10,000 /
100 |
Optimum transparency and heat
resistance.
Ideal for luminous diodes
casting. | |
|
|
|
UL-94-V-O APPROVED SERIES |
|
|
| PRODUCT CODE |
MIXING RATIO |
COLOR |
VISCOSITY (CPS, 25C) |
FEATURES AND APPLICATIONS |
| E-532A / H-532B |
100 :
15 |
Customize
Colors |
9,000 /
100 |
UL-94-V-O listed.
Cure in room
temperature. |
| E-536 / H-536 |
3 : 1 |
Customize
Colors |
42,000 /
160 |
UL-94-V-O listed.
Medium heat cure
epoxy, exhibit good electrical properties, hi-voltage
resistance and excellent heat conductivity. |
| E-537 / H-537 |
100 :
10 |
Customize
Colors |
210,000 |
UL-94-V-O listed.
Medium heat cure
epoxy with hi-voltage resistance. |
| E-759 / H-759 |
100 :
30 |
Customize
Colors |
3,800
/180 |
UL-94-V-O listed.
Cure in room
temperature with minimal flexibility that gives good
impact
resistance. | |
|
|
